Gigabyte X870 EAGLE WIFI7 matična ploča | AM5, DDR5, ATX, Wi-Fi 7

Name: Gigabyte X870 EAGLE WIFI7 AM5 matična ploča | Denitech
SKU: 4719331864996
Price: 28890.00 RSD
Availability: InStock

28.890,00 RSD

Cena je iskazana sa PDV-om.

Gigabyte X870 EAGLE WIFI7 je ATX matična ploča sa AMD X870 čipsetom i AM5 podnožjem. Podržava DDR5 memoriju i ima ugrađene Wi-Fi 7 i 2,5 GbE mrežne veze.

AM5 podnožje i AMD X870 čipset
4 slota za DDR5 memoriju
Wi-Fi 7 i Bluetooth 5.4
2,5 GbE LAN
3 M.2 i 4 SATA priključka

Šifra proizvoda: 4719331864996

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

Samo 10 je preostalo na zalihama

Uporedi

Dodaj u listu želja

Načini plaćanja i dostava

Detaljnije

Zakonska saobraznost dve godine

Saznaj više

Payment Methods:

Specifikacije

Proizvođač	Gigabyte
Socket	AM5
Čipset	AMD X870
Tip memorije	DDR5
Broj memorijskih slotova	4
Format ploče	ATX
WI-FI	Wi-Fi 7
Bluetooth	5.4
Tip	Matična ploča

Opis proizvoda

Gigabyte X870 EAGLE WIFI7

Gigabyte X870 EAGLE WIFI7 je ATX matična ploča sa AMD X870 čipsetom i AM5 podnožjem. Podržava DDR5 memoriju i ima ugrađene Wi-Fi 7 i 2,5 GbE mrežne veze.

Najvažnije karakteristike

AM5 podnožje i AMD X870 čipset
4 slota za DDR5 memoriju
Wi-Fi 7 i Bluetooth 5.4
2,5 GbE LAN
3 M.2 i 4 SATA priključka

Platforma i memorija

Model	Gigabyte X870 EAGLE WIFI7 AM5 DDR5 ATX Matična ploča
Procesorsko podnožje (Socket)	AMD Socket AM5
Skup čipova (Chipset)	AMD X870
Podrška za procesore	AMD Ryzen 9000 Series Processors AMD Ryzen 8000 Series Processors AMD Ryzen 7000 Series Processors
Tip memorije (RAM)	DDR5
Broj memorijskih slotova	4x 288-Pin DDR5
Podrška za memorije	Support for DDR5 8200(OC) / 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory Dual channel memory architecture Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules
Format	ATX

Skladištenje i proširenje

Slotovi za proširenja	1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: AMD Ryzen 900/7000 Series Processors support PCIe 5.0 x16 mode AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: – 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2)
M.2 portovi	3x M.2 Socket 3
Čuvanje podataka – portovi	1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs: AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs AMD Ryzen 8000 Series- Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen 8000 Series- Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x2 SSDs 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSDs The M2B_SB connector shares bandwidth with the M2C_SB connector. The M2B_SB connector operates at up to x2 mode when a PCIe SSD is installed in the M2C_SB connector. 4 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices RAID 5 is only available on AMD Ryzen 9000 Series Processors. RAID 0, RAID 1, and RAID 10 support for SATA storage devices
SATA portovi	4x SATA 6Gb/s

Mreža i povezivanje

Podrška za grafiku – portovi	Integrated Graphics Processor with AMD Radeon Graphics support+ASMedia USB4 Controller: – 2 x USB4 USB Type-C ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840×2160 240Hz Support for DisplayPort 1.4 version and HDR. Integrated Graphics Processor with AMD Radeon Graphics support: – 1 x HDMI port, supporting a maximum resolution of 4096×2160 60Hz Support for HDMI 2.1 version, HDCP 2.3, and HDR. Support native HDMI 2.1 TMDS compatible ports.
LAN	Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Bežična mreža	MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0) – 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands – Support for 11be 160MHz wireless standard Realtek Wi-Fi 7 RTL8922AE (PCB rev. 1.1) – 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands – Support for 11be 160MHz wireless standard
Bluetooth	5.4
Zvuk (Audio)	Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel
USB portovi	CPU+ASMedia USB4 controller: – 2 x USB4 USB Type-C ports on the back panel CPU: – 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel – 1 x USB 3.2 Gen 1 port on the back panel CPU+USB 2.0 Hub: – 4 x USB 2.0/1.1 ports on the back panel Chipset: – 1 x USB Type-C port with USB 3.2 Gen 2×2 support, available through the internal USB header – 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) – 4 x USB 2.0/1.1 ports available through the internal USB headers
Konektori na zadnjoj strani	1 x Q-Flash Plus button 2 x antenna connectors (2T2R) 1 x HDMI port 2 x USB4 USB Type-C ports (DisplayPort) 1 x USB 3.2 Gen 2 Type-A port (red) 3 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks

Ostale karakteristike

Operativni sistem	Windows 11
BIOS	1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Kompatibilnost i ugradnja

Proverite zvaničnu listu podržanih procesora i potrebnu verziju BIOS-a pre ugradnje. Video izlazi zahtevaju odgovarajuću grafiku u procesoru. Dostupne PCIe i M.2 brzine zavise od procesora i raspodele linija. Maksimalne OC frekvencije memorije zavise od modula, procesora i konfiguracije.

Za kućište je potreban prostor za ATX matičnu ploču. Ugrađeni mrežni modul i pojedine funkcije mogu zavisiti od PCB revizije; specifikaciju uporedite sa isporučenom revizijom.

Precizan podatak o uvozniku je dostupan na deklaraciji proizvoda.

Deklaracija

Model:	Matična ploča Gigabyte AM5 X870 EAGLE WIFI7
Robna grupa:	AMD matične ploče
Uvoznik:
Zemlja porekla:
Prava potrošača:	Zagarantovana sva prava kupaca po osnovu zakona o zaštiti potrošača
